Delta VFD1A5MS43ANSAA User Manual

Chapter 15 CANopen OverviewMS300
648
Index
Sub
Definition
Default
R/W
Size
Note
7
Display the output power of U,
V, W in kW
0
R
U16
8
Display the motor speed
estimated by the drive or
encoder feedback in rpm
0
R
U16
9
Display the positive / negative
output torque estimated by the
drive (+0.0: positive torque; -
0.0: negative torque)
0
R
U16
A
Reserved
B
Display the PID feedback
value after enabling the PID
function in % (to two decimal
places)
0
R
U16
C
Display the AVI analog input
terminal signal, 0–10 V
corresponds to 0.00–100.00%
(see Explanation 1 in Pr.00-04)
0
R
U16
D
Display the ACI analog input
terminal signal, 4–20 mA / 0–
10 V corresponds to 0.00–
100.00% (2.) (see Explanation
2 in Pr.00-04)
0
R
U16
F
IGBT temperature of the power
module in
o
C
0
R
U16
2022H
11
The digital input status (ON /
OFF), refer to Pr.02-12
(see Explanation 2 in Pr.00-04)
0
R
U16
12
The digital output status (ON /
OFF), refer to Pr.02-18
(see Explanation 3 in Pr.00-04)
0
R
U16
13
Current step for the multi-step
speed operation
0
R
U16
14
The corresponding CPU digital
input pin status (d.)
(see Explanation 3 in Pr.00-04)
0
R
U16
15
The corresponding CPU digital
output pin status (O.)
(see Explanation 4 in Pr.00-
04 )
0
R
U16
16
Reserved
17
Pulse input frequency (PG2 of
the PG card)
0
R
U16
18
Reserved
1A
Counter value of overload
(0.00–100.00%)
0
R
U16
1B
GFF in %
0
R
U16
1C
DC bus voltage ripples (Unit:
V
DC
)
0
R
U16
1D
PLC register D1043 data
0
R
U16
1E
Magnetic field area of the
synchronous motor
0
R
U16
1F
User page displays the value
in physical measure
0
R
U16
20
Output value of Pr.00-05
0
R
U16
21
Reserved
22
Reserved
23
Reserved
24
Control mode of the drive 0:
speed mode 1: torque mode
0
R
U16
25
Carrier frequency of the drive
0
R
U16
26
Reserved
