Delta VFD1A5MS43ANSAA User Manual

Chapter 15 CANopen OverviewMS300
653
Setting
Display
Fault
Code
Description
CANopen
Fault Register
(bit 0–7)
CANopen
Fault Code
37
0025H
oc hardware error (Hd1)
5
FF08H
40
0028H
Auto-tuning error (AUE)
1
FF21H
41
0029H
PID loss ACI (AFE)
7
FF22H
43
002BH
PG feedback loss (PGF2)
7
7301H
44
002CH
PG feedback stall (PGF3)
7
7301H
45
002DH
PG slip error (PGF4)
7
7301H
48
0030H
ACI loss (ACE)
1
FF25H
49
0031H
External Fault (EF)
5
9000H
50
0032H
Emergency stop (EF1)
5
9000H
51
0033H
External base block (bb)
5
9000H
52
0034H
Password is locked (Pcod)
5
FF26H
54
0036H
Illegal command (CE1)
4
7500H
55
0037H
Illegal data address (CE2)
4
7500H
56
0038H
Illegal data value (CE3)
4
7500H
57
0039H
Data is written to read-only address (CE4)
4
7500H
58
003AH
Modbus transmission time-out (CE10)
4
7500H
61
003DH
Y-connection / Δ-connection switch error
(ydc)
2
3330H
62
003EH
Deceleration energy backup error (dEb)
2
FF27H
63
003FH
Over slip error (oSL)
7
FF28H
72
0048H
S1 internal circuit detection error (STL1)
5
FF30H
76
004CH
STO (STo)
5
FF31H
77
004DH
S2 internal circuit detection error (STL2)
5
FF32H
78
004EH
Internal circuit detection error (STL3)
5
FF33H
79
004FH
U-phase over-current before run (Aoc)
1
FF2BH
80
0050H
V-phase over-current before run (boc)
1
FF2CH
81
0051H
W-phase over-current before run (coc)
1
FF2DH
82
0052H
Output phase loss U phase (oPL1)
2
2331H
83
0053H
Output phase loss V phase (oPL2)
2
2332H
84
0054H
Output phase loss W phase (oPL3)
2
2333H
87
0057H
Low frequency overload protection (oL3)
0
8A00H
