3. Machine Adjustment Procedure
3-5
3-2 Machine Adjustment Procedure
Perform the following operation procedure by using the Digital Keypad (KPVJ-LE01/
KPV-CE01) or the monitoring software VFD-Explorer
Step 1. Enter the motor’s parameters
 Restore the factory default values by setting the Parameter 00-02 = 10
Reset parameter settings
Setting value
of Parameter
00-02
10: Reset parameter values
 Please make sure if the command source has been restored to the factory default (operation
by external terminals)
If the KPV-CE01 is used, the Parameter is 01-01=0
Source of operation command
Setting value
of Parameter
01-01
0: Operation by using the digital keypad
1: Operation by using the external terminals. The Stop button on the
keypad is disabled.
2: Communication using RS-485. The Stop button on the keypad is
disabled
If the VFD-Explorer is used, the Parameter is 01-01=2
Source of operation command
Setting value
of Parameter
01-01
0: Operation by using the digital keypad
1: Operation by using the external terminals. The Stop button on the
keypad is disabled.
2: Communication using RS-485. The Stop button on the keypad is
disabled
 Change the display type from Frequency command (Hz) into Speed (rpm)
Display the speed (rpm) defined by the user
Setting value
of Parameter
00-06
0~39999rpm
 Set the Parameter 01-02
Motor’s maximum operation frequency
Setting value
of Parameter
01-02
50.00 – 600.00Hz
