Delta VFD2A8MS21ANSAA User Manual

Chapter 8 Option CardsMS300
167
Parameter
Function
Current Set Value
Definition of Parameter Values
09-81
Netmask 2
255
Netmask 255.255.255.0
09-82
Netmask 3
255
Netmask 255.255.255.0
09-83
Netmask 4
0
Netmask 255.255.255.0
09-84
Default gateway 1
192
Default gateway 192.168.1.1
09-85
Default gateway 2
168
Default gateway 192.168.1.1
09-86
Default gateway 3
1
Default gateway 192.168.1.1
09-87
Default gateway 4
1
Default gateway 192.168.1.1
Table 8-32
8-5-6 LED Indicator Light & Troubleshooting
There are four LED indicator lights on CMM-EIP03: POWER LED displays the status of the working
power, LINK LED displays the connection status of the communication.
LED Indicators
LED Indicators
Status
Indication
Corrective Action
NET1
(NS)
The red and green
lights flash alternately
Self-test of network status
No action is required
OFF
Network not connected
Check if the network cable is
connected
Red
ON
Duplicate IP
Check if the IP setting is wrong
Flashes
Communication time out /
disconnected / IP changed
Check if the communication
setting is wrong
Green
ON
Network connection in normal status
No action is required
Flashes
Sending / receiving network packet
No action is required
NET2
(MS)
The red and green
lights flash alternately
Self-test of product status
No action is required
OFF
No power supply
Check the power supply
Red
ON
An error cannot be restored occurs
Hardware malfunction, contact
with the dealer
Flashes
An error can be restored occurs
Check if any parameter setting is
wrong
Green
ON
The parameter setting finished
No action is required
Flashes
No parameter setting
Follow manual instructions to set
parameters
POWER
Orange
ON
Power supply in normal status
No action is required
OFF
No power supply
Check the power supply
LINK
Orange
ON
Network connection in normal status
No action is required
Flashes
Sending / receiving network packet
No action is required
OFF
Network not connected
Check if the network cable is
connected
