Chapter 12 Descriptions of Parameter SettingsMS300
276
00-27
User-Defined Value
Default: Read only
Settings
Read only
 Pr.00-27 displays the user-defined value when Pr.00-26 is not set to 0.
00-29
LOCAL / REMOTE Selection
Default: 0
Settings
0: Standard HOA function
1: When switching between local and remote, the drive stops.
2: When switching between local and remote, the drive runs with REMOTE
settings for frequency and operating status.
3: When switching between local and remote, the drive runs with LOCAL
settings for frequency and operating status.
4: When switching between local and remote, the drive runs with LOCAL
settings when switched to Local and runs with REMOTE settings when
switched to Remote for frequency and operating status.
 The default for Pr.00-29 is 0, that is, the standard HOA (Hand-Off-Auto) function. Set the AUTO
and HAND frequency and operation source with Pr.00-20, 00-21 and Pr.00-30, 00-31. The
external terminal function (MI) = 56 for LOC / REM mode selection is disabled when Pr.00-29=0.
 If Pr.00-29 is not set to 0, the top right corner of digital keypad KPC-CC01 (optional) displays
LOC or REM. Set the REMOTE and LOCAL frequency and operation source with Pr.00-20, 00-
21 and Pr.00-30, 00-31. Set the multi-function input terminal (MI) = 56 to set the LOC / REM
selection. The AUTO key on the KPC-CC01 (optional) is the REMOTE function; the HAND key is
the LOCAL function.
 If Pr.00-29 is not set to 0, the AUTO / HAND keys are disabled. In this case, the external terminal
(MI) setting = 56 (local / remote selection) has the highest command priority.

00-30
Master Frequency Command Source (HAND, LOCAL)
Default: 0
Settings
0: Digital keypad
1: RS-485 communication input
2: External analog input (Refer to Pr.03-00)
3: External UP / DOWN terminal (multi-function input terminals)
4: Pulse input without direction command
(Refer to Pr.10-16 without considering direction)
6: CANopen communication card
7: Digital keypad potentiometer knob
8: Communication card (does not include CANopen card)
9: PID controller
NOTE:
HOA (Hand-Off-Auto) function is valid only when you use with MO function
setting 41 and 56 or with KPC-CC01 (optional).
 Determines the master frequency source in the "HAND, LOCAL" mode.
