Delta VFD2A8MS21ANSAA User Manual

Chapter 12 Descriptions of Parameter SettingsMS300
277
 You can switch the HAND, LOCAL mode with the keypad KPC-CC01 (optional) or the multi-
function input terminal (MI) to set the master frequency source.
 It returns to AUTO or REMOTE mode whenever you cycle the power. If you use a multi-function
input terminal to switch between HAND (LOCAL) and AUTO (REMOTE) mode, the highest
priority is the multi-function input terminal. 
 The pulse of Pr.00-30 = 4 (Pulse input without direction command) is input by MI7.
 When Pr.00-30 = 9, Pr.08-65 automatically set as 1 at the same time. Pr.08-65 needs to be set
as 0 for changing back to other values.

00-31
Operation Command Source (HAND, LOCAL)
Default: 0
Settings
0: Digital keypad
1: External terminals
2: RS-485 communication input
3: CANopen communication card
5: Communication card (does not include CANopen card)
NOTE:
HOA (Hand-Off-Auto) function is valid only when you use with MO function
setting 41 and 56 or with KPC-CC01 (optional).
 Determines the operation frequency source in the "HAND, LOCAL" mode.
 In the HOA mode, if the multi-function input terminal (MI) function setting 41 and 42 are OFF, the
drive does not receive any operation command and JOG is invalid.

00-32
Digital Keypad STOP Function
Default: 0
Settings
0: STOP key disabled
1: STOP key enabled
 Valid when the operation command source is not the digital keypad (Pr.00-21 ≠ 0). When Pr.00-
21 = 0, the STOP key on the digital keypad is not affected by this parameter.
00-35
Auxiliary Frequency Source
Default: 0
Settings
0: Master and auxiliary frequency function disabled
1: Digital keypad
2: RS-485 communication input
3: Analog input
4: External UP/DOWN key input (multi-function input terminals)
5: Pulse input without direction command (Refer to Pr.10-16)
6: CANopen communication card
7: Digital keypad potentiometer knob
8: Communication card
