Chapter 12 Descriptions of Parameter SettingsMS300
340
input is lower than the Pr.03-46.
 When setting levels, Pr.03-45 AI upper level must be higher than Pr.03-46 AI lower level.

03-50
Analog Input Curve Selection
Default: 0
Settings
0: Normal curve
1: Three-point curve of AVI
2: Three-point curve of ACI
3: Three-point curve of AVI & ACI

03-57
ACI Lowest Point
Default: 4.00
Settings
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 ≠ 1, 0.00–20.00 mA

03-58
ACI Proportional Lowest Point
Default: 0.00
Settings
0.00–100.00%

03-59
ACI Mid-point
Default: 12.00
Settings
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 ≠ 1, 0.00–20.00 mA

03-60
ACI Proportional Mid-point
Default: 50.00
Settings
0.00–100.00%

03-61
ACI Highest Point
Default: 20.00
Settings
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 ≠ 1, 0.00–20.00 mA

03-62
ACI Proportional Highest Point
Default: 100.00
Settings
0.00–100.00%
 When Pr.03-29 = 1, the ACI setting is 0–10 V and the unit is voltage (V).
When Pr.03-29 ≠ 1, the ACI setting is 0–20 mA or 4–20 mA and the unit is current (mA).
 When you set the analog input ACI to the Frequency command, 100% corresponds to Fmax
(Pr.01-00 Maximum Operation Frequency).
 The requirement for these three parameters (Pr.03-57, Pr.03-59 and Pr.03-61) is Pr.03-57 <
Pr.03-59 < Pr.03-61. The values for three proportional points (Pr.03-58, Pr.03-60 and Pr.03-62)
have no limits. There is a linear calculation between two points.
 The output percentage becomes 0% when the ACI input value is lower than the lowest point
setting.
Example: If Pr.03-57 = 2 mA; Pr.03-58 = 10%, then the output becomes 0% when the ACI input
is ≤ 2 mA. If the ACI input swings between 2 mA and 2.1 mA, the drive’s output frequency
oscillates between 0% and 10%.
