Chapter 12 Descriptions of Parameter SettingsMS300
339

03-32
AFM DC Output Setting Level
Default: 0.00
Settings
0.00–100.00%

03-35
AFM Output Filter Time
Default: 0.01
Settings
0.00–20.00 sec.

03-39
VR Input Selection
Default: 1
Settings
0: Disable
1: Frequency command
 VR is the abbreviation for Variable Resistor; it is the potentiometer of the keyboard panel KPMS-
LE01.

03-40
VR Input Bias
Default: 0.0
Settings
-100–100%

03-41
VR Positive / Negative Bias
Default: 0
Settings
0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while serving as the center
4: Bias serves as the center

03-42
VR Gain
Default: 100.0
Settings
-500.0–500.0%
03-43
VR Filter Time
Default: 0.01
Settings
0.00–2.00 sec.

03-44
Multi-Function Output (MO) by AI Level Source
Default: 0
Settings
0: AVI
1: ACI

03-45
AI Upper Level
Default: 50
Settings
-100.00–100.00%

03-46
AI Lower Level
Default: 10
Settings
-100.00–100.00%
 Use this function with the multi-function output setting 67 (analog input level reached). The MO
is active when the AI input level is higher than the Pr.03-45. The MO is disabled when the AI
