Chapter 6 Control TerminalsMS300

Terminals

Terminal Function

Description

S1, S2

Default: S1 / S2 short-circuited to +24 V

Rated voltage: 24 V

± 10%; maximum voltage: 30 V

± 10%

Rated current: 6.67 mA ± 10%

STO activation mode

Input voltage level: 0 V

< S1-DCM < 5 V

or 0 V

< S2-DCM < 5 V

STO response time ≤ 20 ms (S1 / S2 operates until the AC motor drive stops outputting

current)

STO cut-off mode

Input voltage level: 11 V

< S1-DCM < 30 V

and 11 V

< S2-DCM < 30 V

Power removal safety function per EN 954-1 and IEC / EN 61508

NOTE: Refer to Chapter 17 SAFE TORQUE OFF FUNCTION for details.

DCM

SG+

Modbus RS-485

NOTE: Refer to Chapter 12 DESCRIPTIONS OF PARAMETER SETTINGS parameter

group 09 Communication Parameters for details.

SG-

SGND

RJ45

PIN 1, 2, 6: Reserved

PIN 3, 7: SGND

PIN 4: SG-

PIN 5: SG+

PIN 8: +10 VS (provides KPC-CC01(optional) power supply)

* Analog control signal wiring specification: 0.82 mm

(18 AWG) with shielded stranded wire.

Table 6-3
