Chapter 16 PLC Function ApplicationsMS300
691
Special
D
Function Descriptions
R/W *
D1037
Drive output frequency
RO
D1038
DC bus voltage
RO
D1039
Output voltage
RO
D1040
Analog output value AFM (0.00–100.00%)
RW
D1041
–
D1042
--
--
D1043
Can be user-defined (is displayed on panel when Pr.00-04 is set to 28; display
method is Cxxxx)
RW
D1044
–
D1049
--
--
D1050
Actual operation mode
0: Speed
RO
D1051
–
D1053
--
--
D1054
MI7 current calculated count value (low word)
RO
D1055
MI7 current calculated count value (high word)
RO
D1056
Rotating speed corresponding to MI7
RO
D1057
MI7's rotating speed ratio
RW
D1058
MI7 refresh rate (ms) corresponding to rotating speed
RW
D1059
Number of nibbles of rotating speed corresponding to MI7 (0–3)
RW
D1060
Operation mode setting
0: Speed
RW
D1061
485 Modbus communications time-out time (ms)
RW
D1062
Torque command (torque limit in speed mode)
RW
D1063
–
D1069
--
--
D1100
Target frequency
RO
D1101
Target frequency (must be operating)
RO
D1102
Reference frequency
RO
D1103
–
D1106
--
--
D1107
π (Pi) low word
RO
D1108
π (Pi) high word
RO
D1109
Random number
RO
D1600
The information length that the present 485 received
RO
D1601
The packet accumulation that the present 485 received
RO
D1610
The initial disk D to stack packet
RW
Table 16-13
