Chapter 16 PLC Function ApplicationsMS300
692
16-5-4 PLC Communication address
Device
Range
Type
Address (Hex)
X
00–17 (Octal)
bit
0400–040FF
Y
00–17 (Octal)
bit
0500–050F
T
00–79
bit/word
0600–064F
M
000–799
bit
0800–0B1F
M
1000–1279
bit
0BE8–0CFF
C
0–39
bit/word
0E00–0E27
D
00–199
word
1000–10C7
D
1000–1219
word
13E8–14C3
Table 16-14
Command codes that can be used
Function Code
Function Descriptions
Function target
H1
Coil status read
Y, M, T, C
H2
Input status read
X, Y, M, T, C
H3
Read single unit of data
T, C, D
H5
Force single coil status change
Y, M, T, C
H6
Write single unit of data
T, C, D
HF
Force multiple coil status change
Y, M, T, C
H10
Write multiple units of data
T, C, D
Table 16-15
NOTE:
When PLC functions have been activated, the MS300 can match the PLC and drive parameters; this method
uses different addresses for drives (default station number is 1, PLC sets station number as 2).
