Delta VFD300C43S-HS User Manual

Chapter 3 UnpackingC2000-HS
3-8
Frame G
Remove the six buckles fixed on the crate with a flat-head screwdriver, see the figure below.
1
2
3
4
5
6
Remove the top cover, take out the EPEs and the manual.
Loosen the five screws fasten the drive on the pallet, see the figure below.
1
2
3
4
5
Figure 3-12
Figure 3-13
Figure 3-14
