Chapter 12 Description of Parameter SettingsC2000-HS
12.1-14-2
0–10 V or 4–20 mA. At this moment, Pr.14-10 and Pr.14-11 are invalid.
Setting 1 or 2: Displays the warning code “ANL” on the keypad. It continues blinking until the
lost ACI signal is recovered.
When the motor drive stops, the warning condition does not continue to exist, so the warning
disappears.
Extension Card Output Terminal Selection (AO10)
Extension Card Output Terminal Selection (AO11)
Default: 0
Settings 0–23
Refer to the function chart below for details setting.
Function Chart
Settings Functions Descriptions
0
Output frequency (Hz) Maximum frequency Pr.01-00 is processed as 100%.
1 Frequency command (Hz) Maximum frequency Pr.01-00 is processed as 100%.
2 Motor speed (Hz) Maximum frequency Pr.01-00 is processed as 100%.
3 Output current (rms) (2.5 ᵡ rated current) is processed as 100%
4 Output voltage (2 ᵡ rated voltage) is processed as 100%
5 DC BUS voltage 450V (900V)=100%
6 Power factor -1.000–1.000=100%
7 Power (2 ᵡ rated power) is processed as 100%
8 Torque Full load torque = 100%
9 AVI 0–10 V = 0–100%
10 ACI 4–20 mA = 0–100%
11 AUI -10–10V = 0–100%
12 Iq current command (2.5 ᵡ rated current) is processed as 100%
13 Iq feedback value (2.5 ᵡ rated current) is processed as 100%
14 Id current command (2.5 ᵡ rated current) is processed as 100%
15 Id feedback value (2.5 ᵡ rated current) is processed as 100%
18 Torque command Rated torque of motor = 100%
19 PG2 frequency command Maximum frequency Pr.01-00 is processed as 100%.
20 CANopen analog output For CANopen communication analog output
21 RS-485 analog output For RS-485 (InnerCOM / MODBUS) analog output
22
Communication card
analog output
For communication analog output (CMC-MOD01, CMC-EIP01,
CMC-PN01, CMC-DN01)
23 Constant voltage output
Pr.03-32 controls the voltage output level.
0–100% of Pr.03-32 corresponds to 0–10V of AFM.
25
CANopen and RS-485
analog output
For CANopen and InnerCOM control output
