Delta VFD300C43S-HS User Manual

Chapter 5 Main Circuit TerminalsC2000-HS
5-10
Frame G
W/T3S/L21
+1/DC
S/L22 -/DC-R/L11 T/L31 U/T1 V/T2R/L12 T/L32
 If you install at Ta 50°C environment, please select copper wire with voltage rating 600V and temperature
resistant at 75°C or 90°C.
 If you install at Ta 50°C above environment, please select copper wire with voltage rating 600V and
temperature resistant at 90°C or above.
 For VFD2200C43A-HS, if you install at Ta 45°C above environment, please select copper wire with voltage
rating 600V and temperature resistant at 90°C or above.
 For UL installation compliant, please use copper wires for installation, the wire gauge is based on
temperature resistant at 75°C which is requested and recommended from UL. Do not reduce the wire gauge
when using higher temperature wire.
Model Name
Main Circuit Terminals
R/L11, R/L12, S/L21, S/L22, T/L31, T/L32
Terminal
Max. Wire
Gauge
Min. Wire
Gauge
Screw Spec. and
Torque (±10%)
Max. Wire
Gauge
Min. Wire
Gauge
Screw Spec. and
Torque (±10%)
VFD2200C43A-HS
120 mm
2
*4
[250 MCM*4]
95 mm
2
*4
[3/0 AWG*4]
M8
180 kg-cm
[156.2 lb-in.]
[17.65Nm]
95 mm
2
*4
[3/0 AWG*4]
95 mm
2
*2
[3/0 AWG*2]
M8
180 kg-cm
[156.2 lb-in.]
[17.65Nm]
Model Name
Main Circuit Terminals
U/T1, V/T2, W/T3, +1/DC+, -/DC-
Terminal
Max. Wire
Gauge
Min. Wire
Gauge
Screw Spec. and
Torque (±10%)
Max. Wire
Gauge
Min. Wire
Gauge
Screw Spec. and
Torque (±10%)
VFD2200C43A-HS
240 mm
2
*2
[500 MCM*2]
240 mm
2
*2
[500 MCM*2]
M12
408 kg-cm
[354.1 lb-in.]
[39.98 Nm]
240 mm
2
*2
[500 MCM*2]
240 mm
2
*1
[500 MCM*1]
M8
180 kg-cm
[156.2 lb-in.]
[17.65 Nm]
