Delta VFD300C43S-HS User Manual

Chapter 16 PLC Function ApplicationsC2000-HS
16-46
Command Function
TMR
16-bit timer
Operand
T-K T0–T159, K0–K32,767
T-D T0–T159, D0–D399
When the TMR command is executed, the designated timer coil will be electrified, and
the timer will begin timing. The contact's action will be as follows when the timing
value reaches the designated set value (timing value >= set value):
NO (Normally Open) contact Closed
NC (Normally Close) contact Open
If the RST command has not been executed, the status of the designated element will
remain unchanged.
Ladder diagram:
X0
T5
TMR
K1000
Command code: Description:
LD X0 Load Contact a of X0
TMR
T5 K1000
T5 timer
Set value as K1000
Command Function
CNT
16-bit counter
Operand
C-K C0–C79, K0–K32,767
C-D C0–C79, D0–D399
When the CNT command is executed from Off→On, this indicates that the designated
counter coil goes from no power → electrified, and 1 will be added to the counter's
count value; when the count reaches the designated value (count value = set value),
the contact will have the following action:
NO (Normally Open) contact Closed
NC (Normally Close) contact Open
After the count value has been reached, the contact and count value will both remain
unchanged even if there is continued count pulse input. Please use the RST
command if you wish to restart or clear the count.
Ladder diagram:
X0
C2
CNT K100
Command code: Description:
LD X0 Load Contact a of X0
CNT C2 K100
C2counter
Set value as K100
Command Function
MC/MCR
Connect/release a common series contact
Operand N0–N7
MC is the main control initiation command, and any commands between MC and
MCR will be executed normally. When the MC command is Off, any commands
between MC and MCR will act as follows:
Determination of commands Description
Ordinary timer
The timing value will revert to 0, the coil will lose
power, and the contact will not operate
Counter
The coil will lose power, and the count value and
contact will stay in their current state
Coil driven by OUT command None receive power
Elements driven by SET, RST
commands
Will remain in their current state
Applications commands None are actuated
MCR is the main control stop command, and is placed at the end of the main control program.
There may not be any contact commands before the MCR command.
The MC-MCR main control program commands support a nested program structure with a
maximum only 8 levels; use in the order N0–N7, please refer to the following program:
