Chapter 9 Specification C2000-HS
9-4
9-2 Environment for Operation, Storage and Transportation
DO NOT expose the AC motor drive in the bad environment, such as dust, direct sunlight, corrosive / inflammable gasses,
humidity, liquid and vibration environment. The salt in the air must be less than 0.01mg / cm
2
every year.
Environment
Installation
location
IEC60364-1 / IEC60664-1 Pollution degree 2, Indoor use only
Surrounding
Temperature
(°C)
Storage /
Transportation
-25 – +70
No condense water, non-frozen
Rated Humidity
Operation
Maximum 95%
Storage /
Transportation
Maximum 95%
No condense water
Air Pressure
(kPa)
Operation /
Storage
86–106
Transportation
70–106
Pollution Level
IEC 60721-3-3
Operation
Class 3C3; Class 3S2
Storage
Class 1C2; Class 1S2
Transportation
Class 2C2; Class 2S2
If you use the AC motor drive under harsh environment with high level of contamination
(e.g. dew, water, dust), make sure it is installed in an environment qualified for IP54 such as in
a cabinet.
Altitude
Operation
If AC motor drive is installed at altitude 0–1000m, follow normal operation
restriction. If it is installed at altitude 1000–2000m, decrease 1% of rated
current or lower 0.5°C of temperature for every 100m increase in altitude.
Maximum altitude for Corner Grounded is 2000m.
Package Drop
Storage
ISTA procedure 1A (according to weight) IEC60068-2-31
Transportation
Vibration
1.0mm, peak to peak value range from 2Hz to 13.2 Hz; 0.7G–1.0G range from 13.2Hz to 55Hz; 1.0G range
from 55Hz to 512Hz. Comply with IEC 60068-2-6
Impact IEC / EN 60068-2-27
Operation
Position
Maximum allowed offset angle 10
o
(under normal
installation position)
10 10
Table 9-3
