Chapter 11 Summary of Parameter SettingsC2000-HS
11-9
01 Basic Parameters
Pr. Parameter Name Setting Range Default
01-00 Maximum operation frequency 0.0–1500.0 Hz 600.0
01-01 Output frequency of motor 1 0.0–1500.0 Hz 600.0
01-02 Output voltage of motor 1 0.0–510.0 V 400.0
01-03 Mid-point frequency 1 of motor 1 0.0–1500.0 Hz 3.0
01-04 Mid-point voltage 1 of motor 1 0.0–480.0 V 22.0
01-05 Mid-point frequency 2 of motor 1 0.0–1500.0 Hz 1.5
01-06 Mid-point voltage 2 of motor 1 0.0–480.0 V 10.0
01-07 Min. output frequency of motor 1 0.0–1500.0 Hz 0.5
01-08 Min. output voltage of motor 1 0.0–480.0 V 2.0
01-09 Start-up frequency 0.0–1500.0 Hz 0.5
01-10 Output frequency upper limit 0.0–1500.0 Hz
Depending
on the
models
01-11 Output frequency lower limit 0.0–1500.0 Hz
0
01-12 Acceleration time 1
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
100.00
01-13 Deceleration time 1
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
100.00
01-14 Acceleration time 2
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
100.00
01-15 Deceleration time 2
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
100.00
01-16 Acceleration time 3
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
100.00
01-17 Deceleration time 3
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
100.00
01-18 Acceleration time 4
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
100.00
01-19 Deceleration time 4
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
100.00
01-20 JOG acceleration time
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
10.00
01-21 JOG deceleration time
Pr. 01-45=0: 0.00–600.00 sec.
Pr. 01-45=1: 0.00–6000.0 sec.
10.00
01-22 JOG frequency 0.0–1500.0 Hz
6.0
01-23
First / Fourth acceleration /
deceleration frequency
0.0–1500.0 Hz
0.0
01-24 S-curve acceleration begin time 1
Pr. 01-45=0: 0.00–25.00 sec.
Pr. 01-45=1: 0.0–250.0 sec.
0.20
