Delta VFD370C43S-HS User Manual

Chapter 12 Description of Parameter SettingsC2000-HS
12.1-05-7
Rated Power
Default
Rated Power
Default
Rated Power
Default
[HP] [kW] [HP] [kW] [HP] [kW]
30 22 13.1 150 112 404.3 475 354 3848.5
40 30 18.0 175 130 437.4 535 399 5106.7
50 37 42.1 215 160 687.4
60 45 81.3 250 186 1000.0
75 56 281.5 300 224 1330.0
100 75 327.6 375 279 3330.0
120 89 364.5 420 313 3700.0
Stator Resistance for a Permanent Magnet Motor
Default: 0.000
Settings
0.000
–65.535 
Permanent Magnet Motor Ld
Default: 0.00
Settings
0.00
–655.35 mH
Permanent Magnet Motor Lq
Default: 0.00
Settings
0.00
–655.35 mH

PG Offset Angle for a Permanent Magnet Motor
Default: 0
Settings
0.0
–360.0°
 When you set Pr. 05-00 as 4, the drive detects the offset angle and writes it into Pr. 05-42.

Ke Parameter of a Permanent Magnet Motor
Default: 0.0
Settings
0
–6553.5 V / krpm
 Ke parameter of a permanent magnet motor (V
phase, rms
/ krpm)

When Pr.05-00=5, the induction electromotive force Ke is measured according to the
motor’s
actual opera
t
ion.

When Pr.05-00=13, the Ke is automatically calculated according to the motor power, current and
rotor speed.
