Chapter 12 Description of Parameter SettingsC2000-HS
12.1-06-11
142: Auto-tuning error 1 (no feedback current error) (AUE1)
143: Auto-tuning error 2 (motor phase loss error) (AUE2)
144: Auto-tuning error 3 (no-load current I
0
measuring error) (AUE3)
148: Auto-tuning error (leakage inductance Lsigma measuring error) (AUE4)
When the fault occurs and forces stopping, the fault is recorded in this parameter.
During stop with low voltage Lv (LvS warning), there is no error record. During operation with
mid-low voltage Lv (LvA, Lvd, Lvn error), there is a record.
When dEb function is valid and enabled, the drive executes dEb and records fault code 62 to Pr.
06-17–Pr. 06-22 simultaneously.
Fault Output Option 1
Fault Output Option 2
Fault Output Option 3
Fault Output Option 4
Default: 0
Settings 0–65535 sec. (Refer to bit table for fault code)
Use these parameters with multi-function output terminal (set to 35–38) for the specific
requirement. When the fault occurs, the corresponding terminals activate. Convert the binary
value to decimal value before you enter the value for Pr. 06-23–Pr. 06-26.
Fault Code
bit0 bit1 bit2 bit3 bit4 bit5 bit6
current Volt. OL SYS FBK EXI CE
0: No fault record
1: Over-current during acceleration (ocA)
●
2: Over-current during deceleration (ocd)
●
3: Over-current during constant speed(ocn)
●
4: Ground fault (GFF)
●
5: IGBT short-circuit (occ)
●
6: Over-current at stop (ocS)
●
7: Over-voltage during acceleration (ovA)
●
8: Over-voltage during deceleration (ovd)
●
9: Over-voltage during constant speed (ovn)
●
10: Over-voltage at stop (ovS)
●
11: Low-voltage during acceleration (LvA)
●
12: Low-voltage during deceleration (Lvd)
●
13: Low-voltage during constant speed (Lvn)
●
14: Low-voltage at stop (LvS )
●
15: Phase loss protection (OrP)
●
16: IGBT over-heat (oH1)
●
17: Capacitance over-heat (oH2)
●
18: tH1o (TH1 open)
●
19: tH2o (TH2 open)
●
To Next Page
