Chapter 12 Description of Parameter SettingsC2000-HS
12.1-11-4
Induction motor system inertia (unit: kg-cm
2
):
Rated power
Inertia
Rated power
Inertia
Rated power
Inertia
[HP] [kW] [HP] [kW] HP kW
30 22 17.6 150 112 190.0 475 354 964.3
40 30 20.2 175 130 215.0 535 399 1073.4
50 37 35.5 215 160 280.0
60 45 41.0 250 186 355.0
75 56 49.4 300 224 513.9
100 75 105.6 375 279 598.1
120 89 127.5 420 313 705.3
The base value for PM system inertia is set by Pr.05-38 and the unit is in kg-cm
2
.

ASR1 / ASR2 Switch Frequency
Default: 7.0
Settings 5.0–1500.0 Hz
 The upper limit is the same as the maximum operation frequency for Pr.01-00.
 Sets the low-speed and high-speed ASR switching point in the FOC area. Provides flexibility to
meet two needs: in the high-speed region of the estimator switch point it has a high response,
and in the low-speed region of the estimator switch point it has a lower response. The
recommended switching point is higher than Pr.10-39.
 A low setting does not cover Pr.10-39. If the setting is too high, the high-speed range is too
narrow.

ASR1 Low-speed Bandwidth
Default: 10
Settings 1–40Hz (IM) / 1–100Hz (PM)

ASR2 High-speed Bandwidth
Default: 10
Settings 1–40Hz (IM) / 1–100Hz (PM)

Zero-speed Bandwidth
Default: 10
Settings 1–40Hz (IM) / 1–100Hz (PM)
 After estimating inertia and setting Pr.11-00 bit0=1 (auto-tuning), you can adjust Pr.11-03,
Pr.11-04 and Pr.11-05 separately according to the speed response. The larger the setting value,
the faster the response. Pr.11-02 is the switch frequency for the low-speed / high-speed
bandwidth.
 The position control pulse command (MIx=37) and P2P position control Kp gain can adjust
Pr.11-05. The higher the value, the lower the steady-state error.

ASR 1 Gain
Default: 10
Settings 0–40 Hz (IM) / 1–100Hz (PM)
