Chapter 16 PLC Function ApplicationsC2000-HS
16-77
API
FLT
BIN whole number → binary decimal
transformation
49
D P
Bit device Word device
16-bit command (5 STEP)
FLT Continuous
execution type
FLTP Pulse
execution type
32-bit command (9 STEP)
DFLT Continuous
execution type
DFLTP Pulse
execution type
Flag signal: none
X Y M K H KnX KnY KnM T C D
S * * * * *
D * * * * *
Notes on operand usage: Please refer to the function specifications
table for each device in series for the scope of device usage
The operand D will occupy 2 consecutive points
S: Transformation source device. D: Device storing transformation results.
Transforms BIN whole number into a binary decimal value.
When M200 is On, converts the whole number of values corresponding to D0 and
D1 into floating point numbers, which are placed in D20 and D21.
