Delta VFD370C43S-HS User Manual

Chapter 16 PLC Function ApplicationsC2000-HS
16-82
API
EADD
Adding binary floating point numbers
120
D P
Bit device Word device
16-bit command
－ － － －
32-bit command (9 STEP)
DEADD Continuous
execution type
DEADDP Pulse
execution type
Flag signal: none
X Y M K H KnX KnY KnM T C D
S1 * * *
S2 * * *
D *
Notes on operand usage:
Please refer to the function specifications table for each device in
series for the scope of device usage
 S
1
: addend. S
2
: augend. D: sum.
 When the content of the register designated by S
2
is added to the content of the
register designated by S
1
, and the result is stored in the register designated by D.
Addition is performed entirely using binary floating-point numbers.
 If the source operand S
1
or S
2
designates a constant K or H, the command will
transform that constant into a binary floating point number for use in addition.
 In the situation when S
1
and S
2
designate identical register numbers, if a
"continuous execution" command is employed, when conditional contact is On,
the register will perform addition once during each scan. Pulse execution type
commands (DEADDP) are generally used under ordinary circumstances.
 When X0=On, a binary floating point number (D1, D0) will be added to a binary
floating point number (D3, D2), and the results stored in (D11, D10).
X0
DEADD D0 D2 D10
 When X2 =On, a binary floating point number (D11, D10) will be added to K1234
(which has been automatically converted to a binary floating-point number), and
the results stored in (D21, D20).
X2
DEADD D10 K1234 D20
