3-16
Confluence Machine Tuning Procedure
Wiring according to Chapter 2
Carry out the automatic measurement of the motor’s parameters according to Step 1 and Step 2
described above for the Master and Slave, respectively. Then perform the following procedure
Master setting
Set the Parameter 03-06 = 1
Multifunction Output 2 (MO1)
Setting value
of Parameter
03-06
1: Operation indication
Connect the Master’s MO1 output terminal to the Slave’s SON terminal and Master's MCM
terminal to the Salve's COM terminal.
For the firmware version 2.03 and above, it is not necessary to perform the two steps
described above
Set the Parameter 03-13 = 1
Confluence Master/Slave Selection
Setting value
of Parameter
03-13
0: No function
1: Master 1
2: Slave/Master 2
3: Slave/Master 3
Set the Parameter 03-14
Slave's proportion of the Master’s flow
Setting value
of Parameter
03-14
0.0~6553.5%
For firmware version 2.03 and above, the Parameter 03-17 can be configured to determine the
activation level for the Slave
Slave’s activation level
Setting value
of Parameter
03-17
0~100%
