APX A: Optional Accessories | VFD-VJ
Apx A-5
7. Appearance and specification of brake resistors
7.1Wirewound resistor: for 1000W (included) and above. Refer to the following image for its appearance.
See table below for specification comparison.
A
B
C
D
H
F
K
G
E
L
7.2 Brake Resistors’ model name and comparison
Unit: mm
Model A B C D E F G H ØI ØJ K L
BR1K0W5P1
BR1K2W015
470
±
10
445
±
5
48
±
0.2
9.1
±
0.1
390
±
3
98
±
5
47
±
5
15
±
1
55
±
5
8.1
±
0.1
21
±
0.2
8
±
1
BR1K5W013
