Chapter 9 Specification ME300
9-2
9-1 115V Series
115V, one-phase
Frame A C
Model VFD_ _ _ ME11_ _ _AA
0A8 1A6 2A5 4A8
ANN ANS ANN ANS ANN ANS ANN ANS
Applicable Motor Output (kW) 0.1 0.2 0.4 0.75
Applicable Motor Output (HP) 1/8 1/4 1/2 1
Output Rating
Heavy
duty
Rated Output Capacity (kVA) 0.4 0.6 1.0 1.8
Rated Output Current (A) 0.8 1.6 2.5 4.8
Carrier Frequency (kHz) 2–15
Normal
Duty
Rated Output Capacity (kVA) 0.4 0.7 1.0 2.1
Rated Output Current (A) 1.0 1.8 2.7 5.5
Carrier Frequency (kHz) 2–15
Input Rating
Rated Input
Current (A)
Heavy Duty 3.0 6.0 9.4 18
Normal Duty 3.7 6.8 10.1 20.6
Rated Voltage / Frequency One-phase AC 100–120 V (-15– +10%), 50/60 Hz
Operating Voltage Range (V
AC
) 85–132
Frequency Range (Hz) 47–63
Weight (kg) 0.4 0.4 0.5 1
Cooling Method Convective cooling Fan cooling
EMC Filter Optional
Ingress Protection Rating IP20
The value of the carrier frequency is set in the factory. To increase the carrier frequency, decrease the current. See the derating curve diagram
for Pr.06-55 for more information.
When the load is a shock or impact load, use a higher level model.
NOTE
