Chapter 9 Specification ME300
9-3
9-2 230V Series
230V, one-phase
Frame A B A B A B
Model VFD_ _ _ ME21 _ _ _AA
0A8 1A6 2A8
ANN ANS AFN AFS ANN ANS AFN AFS ANN ANS AFN AFS
Applicable Motor Output (kW) 0.1 0.2 0.4
Applicable Motor Output (HP) 1/8 1/4 1/2
Output Rating
Heavy
duty
Rated Output Capacity (kVA) 0.3 0.6 1.1
Rated Output Current (A) 0.8 1.6 2.8
Carrier Frequency (kHz) 2–15
Normal
Duty
Rated Output Capacity (kVA) 0.4 0.7 1.2
Rated Output Current (A) 1.0 1.8 3.2
Carrier Frequency (kHz) 2–15
Input Rating
Rated Input
Current (A)
Heavy Duty 2.2 3.4 5.9
Normal Duty 2.8 3.8 6.7
Rated Voltage / Frequency One-phase AC 200–240 V (-15– +10%), 50/60 Hz
Operating Voltage Range (V
AC
) 170–265
Frequency Range (Hz) 47–63
Weight (kg) 0.4 0.9 0.4 0.9 0.5 0.9
Cooling Method Convective cooling Fan cooling
EMC Filter Optional Built-in Optional Built-in Optional Built-in
Ingress Protection Rating IP20
Frame B C
Model VFD_ _ _ ME21 _ _ _AA
4A8 7A5 11A
ANN ANS AFN AFS ANN ANS AFN AFS ANN ANS AFN AFS
Applicable Motor Output (kW) 0.75 1.5 2.2
Applicable Motor Output (HP) 1 2 3
Output Rating
Heavy
duty
Rated Output Capacity (kVA) 1.8 2.9 4.2
Rated Output Current (A) 4.8 7.5 11
Carrier Frequency (kHz) 2–15
Normal
Duty
Rated Output Capacity (kVA) 1.9 3.2 4.8
Rated Output Current (A) 5 8.5 12.5
Carrier Frequency (kHz) 2–15
Input Rating
Rated Input
Current (A)
Heavy Duty 10.1 15.8 23.1
Normal Duty 10.5 17.9 26.3
Rated Voltage / Frequency One-phase AC 200–240 V (-15– +10%), 50/60 Hz
Operating Voltage Range (V
AC
) 170–265
Frequency Range (Hz) 47–63
Weight (kg) 0.8 0.9 1 1.5 1 1.5
Cooling Method Convective cooling Fan cooling
EMC Filter Optional Built-in Optional Built-in Optional Built-in
Ingress Protection Rating IP20
NOTE
The value of the carrier frequency is set in the factory. To increase the carrier frequency, decrease the current. See the derating curve diagram
for Pr.06-55 for more information.
When the load is a shock or impact load, use a higher level model.
