Delta VFD4A2ME43ANNAA User Manual

Chapter 11 Summary of Parameter SettingsME300
11-12
Pr. Explanation Settings Default

02-12
Multi-function input mode
selection
0000h–FFFFh (0: N.O.; 1: N.C.) 0000

02-13
Multi-function output 1
RY1
0: No function
1: Indication during RUN
11

02-16
Multi-function output 2
(MO1)
2: Operation speed reached
3: Desired frequency reached 1 (Pr.02-22)
0
4: Desired frequency reached 2 (Pr.02-24)
5: Zero speed (Frequency command)
6: Zero speed including STOP (Frequency command)
7: Over-torque 1 (Pr.06-06–06-08)
8: Over-torque 2 (Pr.06-09–06-11)
9: Drive is ready
10: Low voltage warning (LV) (Pr.06-00)
11: Malfunction indication
13: Over-heat warning (Pr.06-15)
14: Software brake signal indication (Pr.07-00)
15: PID feedback error
16: Slip error (oSL)
17: Count value reached; does not return to 0 (Pr.02-20)
18: Count value reached; returns to 0 (Pr.02-19)
19: External interrupt B.B. input (Base Block)
20: Warning output
21: Over-voltage
22: Over-current stall prevention
23: Over-voltage stall prevention
24: Operation source
25: Forward command
26: Reverse command
29: Output when frequency ≥ Pr.02-34
30: Output when frequency < Pr.02-34
31: Y-connection for the motor coil
32: Δ-connection for the motor coil
33: Zero speed (actual output frequency)
34: Zero speed including STOP (actual output frequency)
35: Error output selection 1 (Pr.06-23)
36: Error output selection 2 (Pr.06-24)
37: Error output selection 3 (Pr.06-25)
38: Error output selection 4 (Pr.06-26)
40: Speed reached (including STOP)
42: Crane function
