Chapter 11 Summary of Parameter SettingsME300
11-13
Pr. Explanation Settings Default
43: Motor speed slower than Pr.02-47
44: Low current output (use with Pr.06-71–06-73)
45: UVW output electromagnetic valve switch
46: Master dEb output
51: Output control for RS-485
66: SO output logic A (use with STO Card)
67: Analog input level reached
68: SO output logic B (use with STO Card)
69: Indication of Preheating
73: Over-torque 3
74: Over-torque 4
75: Forward RUN status
76: Reverse RUN status
77: Program Running Indication
78: Program Step Completed Indication
79: Program Running Completed Indication
80: Program Running Paused Indication
81: Multi-pump system error display (only master)
02-18
Multi-function output
direction
0000h–FFFFh (0: N.O.; 1: N.C.) 0000
02-19
Terminal counting value
reached (returns to 0)
0–65500 0
02-20
Preliminary counting value
reached
(does not return to 0)
0–65500 0
02-22
Desired frequency
reached 1
0.00–599.00 Hz
60.00/
50.00
02-23
Width of desired
frequency reached 1
0.00–599.00 Hz 2.00
02-24
Desired frequency
reached 2
0.00–599.00 Hz
60.00/
50.00
02-25
Width of desired
frequency reached 2
0.00–599.00 Hz 2.00
02-34
Output frequency setting
for multi-function output
terminal
0.00–599.00 Hz 0.00
02-35
External operation control
selection after reset and
activate
0: Disable
1: Drive runs if the RUN command remains after reset or
reboot.
0
02-47 Motor zero-speed level 0–65535 rpm 0
