Chapter 4 Description of Parameters | VFD-VJ
4-3
Pr. Name of Parameter Setting
Factory
Setting
VF
FOCPG
FOCPM
00-04
Selection of
multi-function
display
0: Display the output current (A)
1: Reserved
2: Display the actual output frequency (H)
3: Display the DC bus voltage (U)
4: Display the output voltage (E)
5: Display the output power angle (n)
6: Display the output power in kW (P)
7: Display the actual motor speed rpm (r)
8: Display the estimated output torque N-m
(t) (%)
9: Display the PG feedback (G)
10: Reserved
11: Display the signal value of the analog
input terminal PO % (1.)
12: Display the signal value of the analog
input terminal PI % (2.)
13: Display the signal value of the analog
input terminal AUI % (3.)
14: Display temperature of the heat sink in
°C (t.)
15: Display temperature of IGBT in °C (T)
16: The status of digital input (ON/OFF) (i)
17: The status of digital output (ON/OFF) (o)
18: Reserved
19: The corresponding CPU pin status of the
digital input (i.)
20: The corresponding CPU pin status of the
digital output (o.)
21~24: Reserved
25: Display the signal value of the analog
input terminal QI % (5.)
26: Display the actual pressure value (Bar)
(b.)
27: Display the kWh value (K)
28: Display the motor temperature (currently
only support KTY84) (T.)
29: Overload rate of hybrid servo drive (d.)
(unit: %)
30: Over load rate of motor with last digit A of
HES. (M.) (unit: %)
31: Display current at braking (A.) (unit: A)
32: Temperature of the braking chopper (4.)
(unit: ºC)
33: Reserved
34: Torque constant Kt (K.)
35: Reserved
36: Reserved
37: Reserved
38: Reserved
39: Reseerved
40: Reserved
41: # of times to switch on/off of the soft start
relays (L) (%)
42: Amount of time to clean the cooling fans
(F) %
0 ○ ○ ○
00-05 Reserved 0
00-06
Display the speed (rpm)
defined by the user
0~39999 rpm
2000
○ ○ ○
