Chapter 4 Description of Parameters | VFD-VJ
4-8
01 Motor Parameters You can set this parameter during operation.
Pr. Name of Parameter Setting
Factory
Setting
VF
FOCPG
FOCPM
01-00
Control mode
0: VF
1: Reserved
2: Reserved
3: FOCPGIM (Induction Motor)
4: Reserved
5: FOCPGPM (Permanent Motor)
6: Reserved
7: Reserved
5
01-01
Source of operating
command
0: Controlled by using the digital keypad
1: Controlled by using the external terminals. The
STOP button on the keypad is disabled.
2: Communication using RS-485. The STOP button
on the keypad is disabled
3: Controlled by using CANopen
0
01-02
Motor’s maximum
operating frequency
50.00~599.00Hz
166.67
01-03 Motor’s rated frequency 0.00~599.00Hz 113.33
01-04 Motor’s rated voltage
230V Models: 0.1V~255.0V
460V Models: 0.1V~510.0V
220.0
440.0
01-05
Acceleration time setting 0.00~600.00 seconds
0.00
01-06 Deceleration time setting 0.00~600.00 seconds 0.00
01-07 0: No function 0
1: Dynamic test for induction motor(IM) (Rs, Rr, Lm,
Lx, no-load current)
Motor Parameter Auto
Tuning
2: Static test for induction motor(IM)
3: Reserved
4: Measuring the angle between magnetic pole and
PG origin by the dynamic test of SPM motor
5: Parameter measurement by the dynamic test of
SPM motor (Surface-mounted Permanent Magnet
synchronous Motor)
9: Angle measurement between magnetic pole and
PG origin and parameter measurement by the
dynamic test of SPM motor.
13: Dynamic test for IPM motor
(Interior permanent magnet synchronous motor)
