Chapter 4 Description of Parameters | VFD-VJ
4-14
Pr. Name of Parameter Setting
Factory
Setting
VF
FOCPG
FOCPM
66: Overpressure (ovP)
○ ○ ○
67: Pressure feedback fault (PfbF)
○ ○ ○
68: Oil pump runs reversely (Prev)
69: Oil shortage (noil)
70: Reserved
71: Over current at Braking chopper (ocbs)
72: Braking resistor is open-circuit (bro)
73: Resistance of braking resistor is too small
(brF)
74: Braking chopper overheated (oH4)
75: Error occurred on Brake chopper’s
thermal protection line (tH4o)
76~81: Reserved
82: Output Phase Loss on Phase U (oPL1)
83: Output Phase Loss on Phase V (oPL2)
84: Output Phase Loss on Phase W (oPL3)
85, 86, 88~100: Reserved
87: Hybrid servo drive overloading while
running at low frequency (oL3)
101: Software error 1 occurred on CANopen
(CGdE)
102: Software error 2 occurred on CANopen
(CHbE)
103: Reserved
104: Hardware error occurred on CANopen
(CbFE)
105: Index setting error occurred on
CANopen (CIdE)
106: Slave # setting error occurred on
CANopen (CAdE)
107: CANopen index is out of range (CFrE)
02-07 Low voltage level
160.0~220.0V
DC
320.0~440.0V
DC
180.0
360.0
○ ○ ○
02-08
PTC action selection
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
1
○ ○ ○
02-09 PTC level 0.0~150.0°C
VJ-A: 120°C;
VJ-C : 140°C
○ ○ ○
02-10 Reserved
