Delta VFD750C43A-HS User Manual

Chapter 3 UnpackingC2000-HS
3-4
Frame E
Loosen the 16 screws at the four corners of the crate, and then remove the iron plates.
Remove the top cover, take out the EPEs and the manual.
Loosen the eight screws fasten the drive on the pallet, and then remove the wood plate.
Figure 3-4
Figure 3-5
Figure 3-6

Delta VFD750C43A-HS Specifications

General

Brand	Delta
Model	VFD750C43A-HS
Category	DC Drives
Language	English
