Block Transfer 10

Block Transfer 11

Block Transfer 12

Block Transfer 13

Block Transfer 14

Block Transfer 15

Block Transfer 16
Default: 0000h
Settings 0000–FFFFh
 There is a group of block transfer parameters available in the AC motor drive (Pr. 09-11–Pr.
09-26). Using communication code 03H, you can store the parameters (Pr. 09-11–Pr. 09-26)
that you want to read.
 For example: according to the Address List (as shown in the table below), Pr. 01-42 is shown as
012A. Set Pr. 09-11 to 012Ah (the minimum voltage of Pr. 01-42 M2 is 2.0V), and use Pr. 09-11
(communication address 090B) to read the communication parameter, the read value is 2.0.
AC motor drive
parameters
GGnnH
GG is the parameter group, nn is the parameter number; for
example, the address of Pr. 04-10 is 040AH.
Communication Decoding Method
Default: 1
Settings 0: Decoding Method 1 (20xx)
1: Decoding Method 2 (60xx)
Decoding Method 1 Decoding Method 2
Source of
Operation
Control
Digital Keypad Digital keypad controls the drive action regardless of decoding method 1 or 2.
External Terminal External terminal controls the drive action regardless of decoding method 1 or 2.
RS-485 Refer to address: 2000h–20FFh Refer to address: 6000h–60FFh
CANopen Refer to index: 2020-01h–2020-FFh Refer to index:2060-01h–2060-FFh
Communication Card Refer to address: 2000h–20FFh Refer to address: 6000h–60FFh
PLC PLC command controls the drive action regardless of decoding method 1 or 2.
Internal Communication Protocol
Default: 0
Settings 0: Modbus 485
-1: Internal Communication Slave 1
-2: Internal Communication Slave 2
-3: Internal Communication Slave 3
-4: Internal Communication Slave 4
-5: Internal Communication Slave 5
-6: Internal Communication Slave 6
-7: Internal Communication Slave 7
-8: Internal Communication Slave 8
