Chapter 16 PLC Function ApplicationsC2000-HS
16-63
API
BIN
S D
BCD to BIN transformation
19
D P
Bit device Word device
16-bit command (5 STEP)
BIN Continuous
execution type
BINP Pulse
execution type
32-bit command (9 STEP)
DBIN Continuous
execution type
DBINP Pulse
execution type
Flag signal: none
X Y M K H KnX KnY KnM T C D
S * * * * * *
D * * * * *
Notes on operand usage: none
S
: Data source.
D
: Transformation result.
The content of data source
S
(BCD: 0–9,999) executes BIN transformation
and saves in
D
.
Valid number range of the data source S: BCD (0–9,999), DBCD (0–99,999,999).
When X0 is ON, and the BCD value of K1X20 is transformed to BIN value, the
result saves in D10.
X0
BIN
D10K1X20
When PLC reads a BCD type switch-off from the outside, it has to use the BIN
command to transform the read data to BIN value, then saves the value into PLC.
