Chapter 7 Optional AccessoriesMS300
123
After you confirm the file name, press ENTER.
Begin copying parameters until it is done.
After copying is done, the keypad automatically returns to
this screen.
Press the Right key to see the date of the parameters
copied.
Press the Right key to see the time of the parameters
copied.
6. Fault Record
Press to see an error
record’s details.
Able to store 6 error codes (Keypad V1.02 and previous versions)
Able to store 30 error codes (Keypad V1.20 and later version)
The most recent error record shows as the first record. Choose an error
record to see details such as date, time, frequency, current, voltage, and DC
bus voltage.
Press the Up / Down keys to select an error record.
Press ENTER to see that error record’s details.
Press the Up / Down keys to scroll through an error
record’s details such as date, time, frequency, current,
voltage, and DC bus voltage.
Press ESC to return to the Fault record screen.
Press the Up / Down keys to select the next error
code.
After selecting an error code, press ENTER to see that
error record’s details.
Press the Up / Down keys to see an error record’s
details such as date, time, frequency, current, voltage,
and DC bus voltage.
NOTE:
The AC motor drive actions are recorded and saved to the KPC-CC01.
When you remove the KPC-CC01 and connect it to another AC motor drive, the
previous fault records are not deleted. The new fault records of the new AC motor
drive continue to be added to the KPC-CC01.
