. Remote Control Receiver Window
The remote control receiving signal window , cannot be blocked, otherwise it will affect the remote control
receiving signal.
Kind Reminder: The DAC device does not come with a remote control, which needs to be purchased
separately.
3
Schematic diagram of the effective working angle and distance range of the remote control.
ON
ANALOG
DIGITAL
OPEN TIME0
SOURCE
- +
2 31
5 64
8 97
REPEAT
SCAN REV
PREV
PLAYSTOP PAUSE
PROGRAM NEXT
FWD
A-B RANDOM
- +
SOURCE
OFF
MUTE
VOL +
VOL -
POWER
Receiving end: a cone range of plus or minus 30
degrees on the axis of the IR receiving window;
Effective remote control
Distance: ≤8m
Emitter: A cone range of plus or minus 10 degrees
on the axis of the infrared emitter tube;
