4. SPECIFICATIONS
Description Parameters
Highlight Pure Class-A, True Balanced, Fully Discrete Flagship Line Stage
60 Steps Microprocessor Controlled Relay Based Stepped Attenuator
Precision Matched Military-Specs Metal Film Resistors &
Components with Perfect Channel Balance and Low Distortion
Input IN1 - XLR
IN2 - XLR
IN3 - XLR
IN4 - RCA
Input Impedance Single-Ended 12.2K Ohms
Balanced - 60K Ohms
Output RCA at 2.0Vrms
XLR at 4.0Vrms
Balanced - 400 Ohms
AC Power Requirement 100-240VAC, 50/60Hz (Worldwide Voltage)
Power Consumption 1W (Idle), 25W (Operational)
Frequency Response
10-85k（-0.3dB）
THD+N 0.00012%
S/N Ratio 127dB
Dynamic Range >121dB
