CLOCK OUT lamp
Off: indicates the internal clock
On: External clock
PHASE light
Off: The phase is reversed
On: In phase
NOS(original bit rate) light
Off: Indicates the supersampling rate
On: indicates the original bit rate
DSD lamp
Off: PCM audio
On: DSD audio
COAX lamp, AES 1 lamp, AES 2 lamp
OPT lamp, USB lamp
I2S-A lamp, I2S-B lamp, I2S-C lamp
It changes according to the key change of the
sound source
Off: The audio source is not selected
On: The audio source is selected
Off: The left and right channels of the DSD are L/R
On: The left and right channels of DSD are R/L
1X light, 2X light, 4X light, 8X light
According to the input signal sampling rate n times the frequency change
Off: The input signal is not n times the frequency of the sampling rate
On: The input signal is n times the frequency of the sampling rate
44K1 light, 48K light
Varies according to the sampling rate of the input signal
Off: The input signal is not the sampling rate
On: The input signal is the sampling rate
5
