3. Control button
②.Key description
In Home mode: Press the button to the left to select the source
In menu mode: Press the key to enter CLOCKOUT
Clock output switching mode
In function Settings: Press the button to switch the corresponding clock
In Home mode: Press the button to the right to select a sound source
In menu mode: Press the key to enter CLOCKOUT
Clock output switching mode
In function Settings: Press the button to switch the corresponding clock
Input-key INPUT+ button
The MODE button is pressed
The MODE button toggles between multiple inputs,
Such as optical fiber input, coaxial input, USB input, etc.
OS/NOS (supersampling rate/original bit rate) key
Press this button to switch between OS/NOS modes
On: The system is in NOS mode
Off: The system is in OS mode
Press this button to enable/disable mute.
When muted,The input signal LED will flash
from left to right.
PHASE Keys
Press this button to switch phase output
On: positive phase
Off: The phase is negative
The MUTE button
①.INPUT-, INPUT+, MUTE, OS/NOS, PHASE, MODE. Press these buttons to set the audio input source
output mute state Oversampling rate/source rate, phase reversal and direct control of operating mode.
6
