smartDEN IP-16R-XX User Manual
13 Apr 2021
8.1. Login
Figure 8.3. Login page
Enter the password and click "Login" button. This will bring you to the smartDEN IP-
16R-XX main configuration page which contains details for the current firmware
version and build date and provides buttons and links to obtain further details.
Note: The default password is admin (passwords are case sensitive).
Note: When the password is entered, it is transmitted across the network in
encrypted form, so eavesdropping on the data transmission will not reveal the
password.
Note: In order to prevent setup/control conflicts, at any given moment, only one user
can be logged in.
Note: If there is no data traffic between the Web-browser and the smartDEN IP-16R-
XX for time, specified by Session Timeout parameter, the session "times out" and a
new login is required.
