Denon AVC-2308 User Manual

11
AVR-2308CI / AVR-888 / AVR-2308 / AVC-2308
2. Analog video
2.1. MONITOR OUT (CVBS) Output NG
MONITOR OUT (CVBS) Output NG
※ When checking operation, select
DVD for the function.
(COMPONENT1 input)
Checking the video convert ON/OFF settings
Video convert ON
Video convert OFF
Input
CVBS
Input
S
Input
COMPONENT
Input
CVBS
Input
S
I n p u t
COMPONENT
AB
Interlace
o r
Progressive
D No output No output
Interlace
C
Progressive
no output
2. アナログビデオ
2.1. MONITOROUT(CVBS)出力NG
MONITOROUT(CVBS)出力NG ※ 動作を確認する時はファンクショ
ンを DVD に選択してください。
(COMPONENT1入力 )
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON/OFFの設定確認
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄOFF
入力
CVBS
入力
S
入力
COMPONENT
入力
CVBS
入力
S
入力
COMPONENT
Aへ Bへ ｲﾝﾀｰﾚｰｽ
or
ﾌﾟﾛｸﾞﾚｯｼﾌﾞ
D へ 出力されません 出力されません
ｲﾝﾀｰﾚｰｽ
Cへ
ﾌﾟﾛｸﾞﾚｯｼﾌﾞ
出力されません

Denon AVC-2308 Specifications

General

Type	AV Receiver
Channels	7.1
HDMI Inputs	3
HDMI Outputs	1
Frequency Response	10 Hz - 100 kHz
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	100 dB
Digital Outputs	1 x Optical
Power Output	100 watts per channel into 8 ohms (20 Hz - 20 kHz) at 0.08% THD
Surround Sound Formats	Dolby TrueHD, DTS-HD Master Audio
Audio Formats Supported	MP3, WMA, AAC
Total Harmonic Distortion	0.08%
Digital Inputs	3 x Optical, 2 x Coaxial
Dimensions (W x H x D)	434 x 171 x 379 mm
