The combination of the HEIGHT1, HEIGHT2, HEIGHT3 and HEIGHT4 channels can be changed to the following patterns according to the speaker
system being used.
Set this from “Amp Assign” in the menu. (v p. 226)
Combinations of height speakers to be used
Connected speaker terminals
Number of
height / ceiling
speakers
Number of
Dolby
Speakers
Combination pattern HEIGHT 1 HEIGHT 2 HEIGHT 3
HEIGHT 4/
FRONT
WIDEz1
2ch
2ch None
Front Height Front Height - - -
Top Front Top Front - - -
Top Middle Top Middle - - -
Top Rear Top Rear - - -
Rear Height Rear Height - - -
None 2ch
Front Dolby Front Dolby - - -
Surround Dolby Surround Dolby - - -
Back Dolbyz2
Back Dolby - - -
