9.1-channel playback (bi-amp connection of front speakers: MAIN ZONE) + 2-channel playback
(ZONE2)
This type of configuration plays back 9.1-channels in MAIN ZONE and 2-channels in ZONE2. You can use the bi-amp connection for front speakers in
MAIN ZONE.
.
MAIN ZONE
ZONE2
ZONE2
L
ZONE2
R
C
SW
RSLS
SBL
SBR
FL
(Bi-Amp) (Bi-Amp)
FR
FHL
FHR
.
wq
(R)
wq
(L)
SW
CSRSL
SBR SBL
FHR FHL
zz
FR FL
ZONE2
R
ZONE2
L
z
The height speakers, ceiling speakers and Dolby Atmos Enabled speakers can
be connected to the HEIGHT1 and HEIGHT2 speaker terminals. Set the speaker
to be connected from “Height” in the menu. (v p. 229)
