Preamplifier:
0
All of the speakers are connected using
an external power amplifier and this unit
is used as a preamplifier.
0
You can connect speakers for up to 17.1-
channels for MAIN ZONE.
The pre-out output automatically switches
for playing back up to 15.1-channels in
accordance with the input signals and
sound mode when 17.1-channel speakers
are installed.
Custom:
0
The internal amplifier of this unit is
assigned as desired.
0
You can connect speakers for up to 17.1-
channels for MAIN ZONE.
Set the channel to be assigned to the
speaker terminal in “Settings”. (v p. 224)
o
Floor
n
Layout
Select the floor speakers location.
5ch & SB & FW
(Default):
This layout combines a surround back or
front wide speaker with the basic 5-
channel layout.
5ch & SB:
This layout combines a surround back
speaker with the basic 5-channel layout.
5ch & FW:
This layout combines a front wide
speaker with the basic 5-channel layout.
5ch:
This is a basic 5-channel layout that uses
front speakers, center speakers and
surround speakers.
Contents Connections Playback Settings Tips Appendix
215
Front panel Display Rear panel Remote Index

Denon AVC-A1H Specifications

General

Channels	15.4
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% 2ch Drive)
HDMI Outputs	3
Audio Formats	Dolby Atmos, DTS:X, Auro-3D, IMAX Enhanced
Wireless Connectivity	Wi-Fi, Bluetooth
Type	AV Amplifier
IMAX Enhanced	Yes
8K/60Hz Pass-through	Yes
4K/120Hz Pass-through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
THD	0.05%
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
Signal-to-Noise Ratio	102 dB
Ethernet	Yes
USB Port	Yes
Multi-Room Audio	HEOS
Amplifier Type	Class AB
