Denon AVR-2313CI Model Information

Front Panel (1 of 2)
HOME
DISPLAY
2
 Ipod/USB port
Used to connect USB storages (such as USB memory devices) and the
USB cable supplied with iPod.
 AUX INPUT connectors
Remove the cap covering the connectors when you want to use
them.
 Power operation button (O)
Turn power to this unit on and off (standby).
 Power indicator
This is lit as follows according to the power status:
• Power on : Green
• Normal standby : Off
• When “HDMI Control” is set to “On” : Red
• When “IP Control” is set to “Always On” : Red
 Headphones jack (PHONES)
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers.
NOTE
• To prevent hearing loss, do not raise the volume level excessively
when using headphones.
 AUX-HDMI connector
Used to connect devices such as video cameras and game consoles.
FRONT PANEL 2

Denon AVR-2313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	10899 g
