Denon AVR-S570BT User Manual

Adjusting audio delay (Audio Delay)
Compensates for incorrect timing between video and audio.
1
Press OPTION.
The option menu screen is displayed.
2
Use ui to select “Audio Delay”, then press ENTER.
The “Audio Delay” screen is displayed.
3
Use o p to adjust the timing.
0 ms – 200 ms (Default : 0 ms)
0
“Audio Delay” settings are stored for each input source.
0
The “Audio Delay” settings can be set even if AUDIO DELAY + or AUDIO DELAY -
is pressed on the remote control unit.
Optimizing the night time listening
volume (Night Mode)
Compress dynamic range (difference between loud and soft sounds).
This can be set when a Dolby Digital signal is input.
1
Press OPTION.
The option menu screen is displayed.
2
Use ui to select “Night Mode”, then press ENTER.
The Night Mode setting screen is displayed.
3
Use o p to select “Night Mode”, then press ENTER.
Low : Set the adjusted value to low.
Medium : Set the adjusted value to middle.
High : Set the adjusted value to high.
Auto :
Automatic dynamic range compression
on/off control according to the source.
Off
(Default):
Do not set.
0
“Auto” can be set when a Dolby TrueHD signal is input.
0
The default setting is “Off”.
Contents Connections Playback Settings Tips Appendix
58
Front panel Display Rear panel Remote Index

Denon AVR-S570BT Specifications

General

Channels	5.2
Power Output	70W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Outputs	1
4K/60Hz Pass-through	Yes
Bluetooth	Yes
Dolby Vision	Yes
HDR10	Yes
HDCP 2.3 Support	Yes
HDMI 2.1	No
4K/120Hz pass-through	No
HDR Support	Yes
eARC	Yes
Dolby Technologies	Dolby TrueHD, Dolby Digital Plus
DTS Technologies	DTS-HD Master Audio
Frequency Response	10Hz-100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV
Input Sensitivity/Impedance	200 mV / 47 kΩ
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
