Denon AVR-S570BT User Manual

Display
tyreqw
ui
A
Input mode indicators
These light according to the audio input mode settings of each input
source. (v p. 88)
B
Decoder indicators
These light when Dolby or DTS signals are input or when the Dolby or
DTS decoder is running.
C
Tuner reception mode indicators
These light up according to the reception conditions when the input
source is set to “Tuner”.
TUNED: Lights up when the broadcast is properly tuned in.
STEREO: Lights up when receiving FM stereo broadcasts.
D
Sleep timer indicator
This lights when the sleep mode is selected. (v p. 66)
E
Volume indicator
F
MUTE indicator
This blinks while the sound is muted. (v p. 41)
G
Information display
The input source name, sound mode, setting values and other
information are displayed here.
H
Input signal indicators
The respective indicator will light corresponding to the input signal.
(v p. 88)
Contents Connections Playback Settings Tips Appendix
14
Front panel Display Rear panel Remote Index

Denon AVR-S570BT Specifications

General

Channels	5.2
Power Output	70W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Outputs	1
4K/60Hz Pass-through	Yes
Bluetooth	Yes
Dolby Vision	Yes
HDR10	Yes
HDCP 2.3 Support	Yes
HDMI 2.1	No
4K/120Hz pass-through	No
HDR Support	Yes
eARC	Yes
Dolby Technologies	Dolby TrueHD, Dolby Digital Plus
DTS Technologies	DTS-HD Master Audio
Frequency Response	10Hz-100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV
Input Sensitivity/Impedance	200 mV / 47 kΩ
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
