Denon AVR-S570BT User Manual

Q
9
Q
6
Q
7
Q
8
W
0
Q
5
Q
4
N
Headphones jack (PHONES)
This is used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers or from the SUBWOOFER
connectors.
NOTE
0
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
O
SETUP MIC jack
This is used to connect the supplied Sound calibration microphone.
(v p. 92)
P
QUICK SELECT buttons
With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings. (v p. 68)
Q
TONE CONTROL ON/OFF button
Set the tone control function to on/off. (v p. 57)
R
BASS/TREBLE button
Selects the range for which to adjust the tone. (v p. 57)
S
USB port (T)
This is used to connect USB storages (such as USB memory devices)
and the USB cable supplied. (v p. 35)
T
Tone adjustment buttons (ADJUST 0 1)
Adjusts the tonal quality of the sound. (v p. 57)
0
BASS/TREBLE button and ADJUST 0 1 buttons can be operated when the
“Tone” setting is “On”. (v p. 57)
Contents Connections Playback Settings Tips Appendix
13
Front panel Display Rear panel Remote Index

Denon AVR-S570BT Specifications

General

Channels	5.2
Power Output	70W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Outputs	1
4K/60Hz Pass-through	Yes
Bluetooth	Yes
Dolby Vision	Yes
HDR10	Yes
HDCP 2.3 Support	Yes
HDMI 2.1	No
4K/120Hz pass-through	No
HDR Support	Yes
eARC	Yes
Dolby Technologies	Dolby TrueHD, Dolby Digital Plus
DTS Technologies	DTS-HD Master Audio
Frequency Response	10Hz-100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV
Input Sensitivity/Impedance	200 mV / 47 kΩ
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
