Denon AVR-S570BT User Manual

retqw y
Q2Q1Q0 Q3oiu
A
Power operation button (X)
Used to turn the power on/off (standby). (v p. 40)
B
Power indicator
This is lit as follows according to the power status:
0
Green: Power on
0
Off: Normal standby
0
Red:
0
When “HDMI Pass Through” is set to “On” (v p. 81)
0
When “HDMI Control” is set to “On” (v p. 81)
0
When “Bluetooth Standby” is set to “On” (v p. 100)
C
SOURCE SELECT knob
This selects the input source. (v p. 40)
D
Remote control sensor
This receives signals from the remote control unit. (v p. 7)
E
Display
This displays various pieces of information. (v p. 14)
F
MASTER VOLUME knob
This adjusts the volume level. (v p. 41)
G
SOUND MODE buttons (0 1)
These select the sound mode. (v p. 60)
H
Tuner preset channel buttons
(TUNER PRESET CH +, –)
These select preset broadcast stations. (v p. 52)
I
Tuning buttons (TUNE +, –)
Select either FM broadcast or AM broadcast. (v p. 50)
J
Tuning mode select button (MODE)
This switches the tuning mode. (v p. 50)
K
SLEEP button
This sets the sleep timer. (v p. 66)
L
DIMMER button
Each press of this switches the brightness of the display. (v p. 102)
M
STATUS button
Each press of this switches the status information that is shown on the
display.
Contents
Connections Playback Settings Tips Appendix
12
Front panel Display Rear panel Remote Index

Denon AVR-S570BT Specifications

General

Channels	5.2
Power Output	70W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Outputs	1
4K/60Hz Pass-through	Yes
Bluetooth	Yes
Dolby Vision	Yes
HDR10	Yes
HDCP 2.3 Support	Yes
HDMI 2.1	No
4K/120Hz pass-through	No
HDR Support	Yes
eARC	Yes
Dolby Technologies	Dolby TrueHD, Dolby Digital Plus
DTS Technologies	DTS-HD Master Audio
Frequency Response	10Hz-100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV
Input Sensitivity/Impedance	200 mV / 47 kΩ
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
