Denon AVR-S650H User Manual

5
2) Connect the receiver to your home network
Wired LAN
Connect an Ethernet cable (not included) between your
receiver and your network router.
PRE OUT
2
SUBWOOFER
AUDIO
(
ASSIGNABLE
)
IN
AUDIO
IN
CBL/SAT 2 MEDIA
PLAYER
1 TV
AUDIO
OPTICAL
IN
DIGITAL AUDIO
(
ASSIGNABLE
)
COAXIAL
MONITOR
VIDEO
OUT
1 CBL/SAT 2 AUX
1 CBL/SAT
2 AUX
(
ASSIGNABLE
)
SIGNAL GND
PHONO
ANTENNA
FMAM
VIDEO
IN
1
Router
To LAN port
Wireless LAN
Rotate the two antennas located on the back of the receiver
upwards for maximum performance.
PRE OUT
2
SUBWOOFER
AUDIO
(
ASSIGNABLE
)
IN
AUDIO
IN
CBL/SAT 2 MEDIA
PLAYER
1 TV
AUDIO
OPTICAL
IN
DIGITAL AUDIO
(
ASSIGNABLE
)
COAXIAL
MONITOR
VIDEO
OUT
1 CBL/SAT 2 AUX
1 CBL/SAT
2 AUX
(
ASSIGNABLE
)
SIGNAL GND
PHONO
ANTENNA
FMAM
VIDEO
IN
1
1. AVR-S650HE3_QSG_ENG_10A_190130.indd 5 2019/01/30 14:56:01
PrintingColor:Black

Denon AVR-S650H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supported	JPEG
HDCP	Yes
Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	340 W
Package weight	9525 g
Package width	523 mm
Package height	229 mm

Weight and Dimensions

Depth	330 mm
Width	432 mm
Height	152 mm
Weight	7800 g
